brand:
pvcellschainSealed Type:
VRLAVoltage:
2Vcapacity:
50Ah - 3000AhMaintenance Type:
Free MaintenanceCycle Life:
Deep CycleCertificate:
CE, ISO14001, ISO9001Lead Time:
7 DaysPayment:
T/T, Paypal, Western UnionWarranty:
3 YearsProduct Name:2V GEL VRLA Battery
Voltage:2V
Capacity:From 50Ah to 3000Ah
Designed floating service life:20 Years at 20°C/68°F
General Features
Sealed and Maintenance-free Operation
Wide operating temperature range from -15°C to 60°C
Float current decreased 30% lead to excellent high temperature resistance
Electrolyte immobilized as gel state, no leakage and no stratification
Low self-discharge rate and long shelf life (1 year at 25°C)
Excellent deep discharge recovery capability
Supper deep cycle life and stability at high temperature
Construction
Positive plate – Thick high Sn low Ca grid minimize corrosion and prolong life
Negative plate – Balanced Pb-Ca grid for improved recombination efficiencys
Separator – Imported Daramic PVC separator for Gel battery
Electrolyte – Dilute high purity sulphuric acid with nano gel
Battery container and cover – ABS
Pillar seal – 100% factory tested, proven two layers epoxy resin seal
Relief valve – Complete with integrated flame arrestor
Typical Applications
Telecom
Power plant and power transformer systems
Radio and broadcasting stations
Navigation and signaling systems
Emergency power systems
UPS systems
Other spares&circulatory systems
Pitched Roof Mounting Support for Solar Panels, Pre-assembly and flexibility, Low cost and high application, Anti-corrosion, 100% recycled, Portable and beautiful.
pvcellschain 12V 24V 48V 30A 40A 50A 60A Mppt Solar Charge Controller Easy to set up and operate, suitable for home, industrial, commercial etc.
20A 30A 40A 50A 60A MPPT Solar Charge Controller Easy to set up and operate, suitable for home, industrial, commercial etc.
US market split phase 10kw 12kw 5kw solar panel system with 12kw hybrid solar inverter
Hot Sale & Clean Energy On-Grid Solar Energy System for your whole house, it connects with the grid,lower the electricity cost. Accept specially customized to meet your different requirements.
182mm Monocrystallin Half Cell Solar Panels
Our 60W Endurance Solar Lights provide a cost effective, energy efficient, and long term outdoor lighting solution, giving you a completely off the grid option.
Deep Cycle 12V 200Ah GEL Solar Battery AGM Storage Battery Products Specification Model 6-GFM-200Ah 6-GFM(G)-200Ah Cells Per Unit 6 Voltage Per Unit 12 Capacity 200Ah@10hr-rate to 1.80V per cell @25°C Weight 57.9kg 62.4kg Internal Resistance Approx. 3 mΩ Approx. 3.5 mΩ Terminal F8 Max.Discharge Current 3000A (5 sec) Design Life 6~8 years 10~15 years Maximum Charging Current 50A Reference Capacity C10 200.0AH C3 153.3AH C1 110.4AH C10 200.0AH C3 144.7AH C1 110.1AH Float Charging Voltage 13.6 V~13.8 V @ 25°C Temperature Compensation: -20mV/°C/Cell Cycle Use Voltage 14.4 V~14.9 V @ 25°C Temperature Compensation: -30mV/°C/Cell Operating Temperature Range Discharge: -15°C~50°C Charge: 0°C~40°C Storage: -15°C~40°C Discharge: -20°C~60°C Charge: 0°C~50°C Storage: -20°C~60°C Normal Operating Temperature Range 25°C±5°C Self Discharge Less than 3% at 25°C per month Container Material A.B.S. UL94-HB, UL94-V0 Optional Detailed Images Products Projects
